L.B. White Volt 9 Electric Forced-Air Heater — 9 kW, 240 V, Single Phase

Portable electric forced-air heater for localized heating and drying. Selectable 6 kW (20,500 BTU/h) and 9 kW (30,700 BTU/h) heat output. Combustion-free operation eliminates fuel handling and combustion odors.

Applications

• Swine facility maintenance and temporary heating or drying
• Portable heating and drying applications

Specifications

• Model: Volt 9
• Heat output: Selectable 6 kW (20,500 BTU/h) and 9 kW (30,700 BTU/h) heat output.
• Electrical supply: 240 V / 60 Hz / single phase
• Operating current: 37.5 A
• Airflow: 350 CFM
• Plug: NEMA 14-50P
• Ambient thermostat: 32–100 °F
• Manufacturer packaged shipping weight: 42 lb (19.05 kg)

Installation & Compatibility

• Industrial-grade fan and sealed motor
• Stainless-jacketed heating coils and powder-coated steel housing
• Quiet, combustion-free operation with overheat protection
• Use a properly rated electrical circuit; consult a qualified electrician and the manufacturer’s installation instructions before use

Documents & Downloads

• Volt Electric Heater Brochure (PDF)
• Volt 9 Owner's Manual (PDF)
